FD3125L – Eaton Cutler-Hammer 125 Amp 3 Pole 600 Volt Molded Case Thermal Magnetic Circuit Breaker
Cutler Hammer / Eaton / Westinghouse, Series C, type FD, 3P, 3PH, 125A, 600V, 35kA@480V, standard interrupting capacity, 40 degree C, feed-thru, complete with non-interchangeable trip, LI – Long-Time and Instantaneous trip functions and line & load side lug terminals, thermal magnetic, molded case circuit breakers
- Manufacturer: Eaton Cutler Hammer
- Type: FD
- Family: Series C
- UL Listed
Interrupting Rating
- AIC Rating: 35kA@480V
- AIC Rating: 65kA@240V
Specifications
- F Frame
- 3 Pole
- 125 Amp
- 600 Volt
- 3 Phase
- Protection: Thermal Magnetic
- Functions: LI – Long-Time and Instantaneous
- Dimensions (H x W x L): 6″ x 4.13″ x 3.38″
