BQD240 – Siemens 40 Amp 2 Pole 480 Volt Bolt-On Molded Case Circuit Breaker

$507.38

BQD240 – Siemens 40 Amp 2 Pole 480 Volt Bolt-On Molded Case Circuit Breaker

Availability: 25 in stock

SKU: DM-BQD240 Categories: , Tag:

BQD240 – Siemens 40 Amp 2 Pole 480 Volt Bolt-On Molded Case Circuit Breaker

Siemens / ITE Bolt-On Circuit Breaker Its Compact And Easy to Install two poles molded case circuit breaker features a thermal magnetic over current protection system it has a voltage rating of 480Y/277 Vac 125/250 Vdc and current rating of 40 amps at 40 deg c and frequency rating of 60 Hz it has an interrupt current rating of 65 kiloampere At 240 Vac circuit breaker is designed with a bolt-on connection type with a terminal load lug the circuit breaker has a BQD type of frame and circuit breaker is Ul listed csa certified.

Specifications:

  • Product Lifecycle (PLM): PM300:Active Product
  • Net Weight (lb): 1.1 lb
  • Product Group: 5361
  • Compliance with the substance restrictions according to RoHS directive: Since: 07/01/2006
  • Authentic Siemens Product
  • Voltage Rating: 480 Volt
Connection

Bolt-On

Max Amp

40A

Voltage

480V
